Requirements for use
3.2 Project engineering
CP 343-1
28 Manual, 12/2018, C79000−G8976−C201-08
3.2
Project engineering
Software versions
The following version of STEP 7 is required:
Table 3- 4 Configuration tools for the CP 3431
STEP 7 versions
Function
STEP 7 V5.5, Service Pack 2, Hotfix 4, HSP 1057 Requirement for configuration of the CP with the functions of
firmware version 3.0
STEP 7 Professional V11, Service Pack 2, Update 2 Requirement for configuration of the CP with the functions of
firmware version 2.4
Locating the support package
You can install the support package from your local file system if it is already stored there or
from the Internet pages of Siemens Automation Customer Support.
STEP 7 V5.5
You will find the support package (HSP) on the Internet at the following address:
23183356 (http://support.automation.siemens.com/WW/view/en/23183356)
STEP 7 Professional V11
You will find the support package on the Internet at the following addresses:
28919804 (http://support.automation.siemens.com/WW/view/en/28919804)
or
10806075 (http://support.automation.siemens.com/WW/view/en/10806075)
On the Internet page, select the "Entry list" tab and the "Download" entry type.
Installation of the support package
STEP 7 V5.5
Install the HSP in STEP 7 / HW Config with the "Options" > "Install Hardware Updates"
menu command.
You will find further information in the STEP 7 online help (under "HSP" or "Hardware
update"). After installing the HSP, close STEP 7. After restarting STEP 7, the CP is in the
catalog of HW Config.
STEP 7 Professional V11
Install the support package in STEP 7 using the menu command "Options" > "Support
packages".
The information system of STEP 7 will provide you with information (keyword "Support
Packages" or Installing Support Packages"). After installing the support package, close
STEP 7. After restarting STEP 7, the CP is in the catalog.
