Preface
CP 343-1
4 Manual, 12/2018, C79000−G8976−C201-08
Note
Names
•
In this document, the term "CP" is used instead of the full product name.
•
The name STEP 7 is used for the configuration tool instead of the names STEP 7 V5.5
and STEP 7 Professional.
New in this edition
New ATEX/IECEx approval
Replaced documentation
This manual replaces the manual edition 10/2012.
Innovations and compatibility with the predecessor product
Note
You will find the new functions of the module in the section
Enhanced functions (Page 11).
Make sure that you read the information relating to enhanced functions and restrictions in the
section
Module replacement / upgrading (Page 60).
Address label: Unique MAC address preset for the CP
The CP ships with a default MAC address. The MAC address is printed on the housing.
Address label: Unique MAC address for the CP
The CP is supplied with total of 3 default MAC addresses with the following assignment:
● PROFINET interface
● One MAC address for each of the 2 Ethernet ports of the PROFINET interface
The MAC addresses of the Ethernet ports are required only for detection and evaluation
of neighborhood and topology relations.
The MAC address of the PROFINET interface is printed on the housing.
If you configure a MAC address (ISO transport connections), we recommend that you use
the MAC address printed on the module for module configuration!
● This ensures that you assign a unique MAC address in the subnet!
● If you replace a module, the MAC address of the predecessor is adopted when you load
the configuration data; configured ISO transport connections remain operable.
You should also refer to the information in the section Replacing a module (Page 59).

Siemens CP 343-1 Specifications

General

Product Type Designation	CP 343-1
Power Supply	24 V DC
Protection Class	IP20
Product Type	Communications processor
Interface	Ethernet
Data Transmission Rate	10/100 Mbit/s
Protocols Supported	TCP/IP, UDP
Number of Ports	1
Operating Temperature	0 to 60 °C
