CONTROL PANEL INSTALLATION
PARTS SUPPLIED – FC901
FC901 Enclosure Assembly FH901-U3(Black)/FH902-U3(Red)
FC901 Main Board Assembly FCM901-U3
Power Supply Assembly FP2011-U1
FC901 City Tie Module Assembly (optional) FCI2020-U1
FC901 Configuration Kit (optional) FXS901-U3
1. FC901 Enclosure Package
FC901 black enclosure
Description
Part No.
Qty
FC901 enclosure black
A5Q00039701
1
Installation instruction
A5Q00039693
1
T45 key
N/A
2
#8-32 grounding cable nut
N/A
2
FC901 red enclosure
Description
Part No.
Qty
FC901 enclosure
A5Q00039702
1
Installation instruction
A5Q00039693
1
T45 key
N/A
2
#8-32 grounding cable nut
N/A
2
2. FC901 Main Board Package
Description
Part No.
Qty
FC901 main board
A5Q00039689
1
FC901 main board support
frame
A5Q00039705
1
FC901 English film
A5Q00039715
1
FC901 English strip
A5Q00042803
1
FC901 rubber key
A5Q00042362
1
FC901 battery bracket left
(optional)
A5Q00039703
1
FC901 battery bracket right
(optional)
A5Q00039704
1
FC901 battery cable
A5Q00039710
1
FC901 battery cable to main
board
A5Q00039711
1
FC901 earth cable
A5Q00042829
1
Terminal block 2 pin
A5Q00011337
8
Terminal block 3 pin
X7403000
4
Terminal block 4 pin
A5Q00016176
2
FC901 cable ties
A5Q00036742
6
21
