hwc_vnsconfiguration.fm
A31003-W1040-U101-1-7619, July 2006 DRAFT
HiPath Wireless Controller, Access Points and Convergence Software V4.0, C10/C100/C1000 User Guide
171
Virtual Network configuration
Configuring privacy for a VNS
● Dynamic keys
● Wi-Fi Protected Access (WPA) version 1, with encryption by Temporal Key Integrity
Protocol (TKIP)
● Wi-Fi Protected Access (WPA) version 2, with encryption by Advanced Encryption
Standard with Counter-Mode/CBC-MAC Protocol (AES-CCMP)
To set up static WEP privacy for an AAA VNS:
1. From the main menu, click Virtual Network Configuration. The Virtual Network
Configuration screen appears.
2. In the left pane Virtual Networks list, click the AAA VNS you want to configure privacy by
WPA-PSK for a Captive Portal. The Topology tab is displayed.
3. Click the Privacy tab.
4. Select Static Keys (WEP).
5. From the WEP Key Length drop-down list, select the WEP encryption key length:
● 40-bit
