Siemens LMV3 series User Manual

Error
Code
Diag.
Code
Meaning for the LMV3 System Corrective Action
Note: Diagnostic codes are additive. If a diagnostic code appears that is not on this list, it is a combination of multiple diagnostic codes.
Any # Manual locking
1 Manual locking by contact
2 Manual locking by AZL23
3 Manual locking by PC software
8 Manual locking by AZL23 - timeout / communication breakdown
During a curve adjustment on the AZL23, the timeout for menu operation
has elapsed (parameter 127), or communication between the LMV3 and
AZL23 has been lost. Re-establish communication and reset the fault.
9 Manual locking by PC software - communication breakdown
During a curve adjustment on the ACS410 software, communication
between the LMV3 and the ACS410 software has been lost for more than
30 seconds. Re-establish communication and reset the fault.
33 Manual locking by PC software - test of lockout
A reset was made via the ACS410 software when the LMV3 was not in
alarm. Reset the LMV3 to clear the fault.
168 Any # Internal error management
169 Any # Internal error management
170 Any # Internal error management
171 Any # Internal error management If the fault occurs continuously, replace the LMV3.
200
OFF
Any # System error-free The LMV3 displays this code when there are no current faults.
Any # Prevention of startup
1 No operating mode selected
2 No fuel train defined
4 No curves defined
8 Standardized speed undefined
16 Backup / restore was not possible
202 Any # Internal error operating mode selection Make a valid selection of parameter 201/301, then reset the fault.
203 Any # Internal error
Make a valid selection of parameter 201/301, then reset the fault. If the
fault occurs continuously, replace the LMV3.
24 Program stop is active (phase 24)
36 Program stop is active (phase 36)
44 Program stop is active (phase 44)
52 Program stop is active (phase 52)
205 Any # Internal error If the fault occurs continuously, replace the LMV3.
If the fault occurs continuously, replace the LMV3.
167
No fault: The program stop feature is active. Set parameter 208 to 0 to
deactivate the program stop if it is no longer required.
The LMV3 cannot startup because a parameter is not defined. The
diagnostic code calls out which parameter is not defined. Choose a valid
selection for the undefined parameter and then reset the fault.
The LMV3 has been manually locked (no fault). Reset the LMV3 to clear
the fault.
201
OFF UPr0
OFF Upr1
204
