Siemens LMV3 series User Manual

LMV Series Technical Instructions
Document No. LV3-1000
SCC Inc. Page 7 Section 7
Function
Address
dec/hex
Number
of words
Data designation
Access
Data
format
Data type /
coding
Range
R 03/04
W 06/16
38
/26h
1
Program stop
R/W*
EEPROM
U16
0=deactivated
1=24 PrePurgP
2=36 IgnitPos
3=44 Interv 1
4=52 Interv 2
0...4
R 03/04
W 06/16
41
/29h
1
Modbus mode:
Preselected output
local / preselected output remote
(default setting: 0)
R/W
U16
0 = Local
1 = Remote
0…1
R 03/04
W 06/16
42
/2Ah
1
Modbus breakdown
time:
Max. time with no communication.
When this time has elapsed,
automatic change from Remote to
Local will take place
R/W*
EEPROM
U16
0…7200 s
0 = inactive
R 03/04
W 06/16
43
/2Bh
1
Operating mode in Remote
operation:
Auto, Remote ON, Remote OFF
(default setting: 0)
R/W
U16
0 = Auto
1 = ON
2 = OFF
0…2
R 03/04
W 06/16
45
/2Dh
1
P
reselected target output
modulating / multistage
R/W
U16
Fire rate
Modulating:
0…100%
Multistage:
1001…1003
Invalid:
32767
R 03/04
W 06/16
56
/38h
2
Hours run
fuel 0 resettable
R/W*
EEPROM
S32
0...999999 h
R 03/04
W 06/16
58
/3Ah
2
Hours run
fuel 1
resettable
R/W*
EEPROM
S32
0...999999 h
R
03/04
68
/44h
2
Hours run
unit live
R
S32
0...999999 h
R 03/04
W 06/16
70
/46h
2
Start
counter
fuel 0 resettable
R/W*
EEPROM
S32
0...999999
R 03/04
W 06/16
72
/48h
2
Start
counter
fuel 1 resettable
R/W*
EEPROM
S32
0...999999
03/04
76
/4Ch
2
Start
counter total (read only)
R
S32
0...999999
03/04
78
/4Eh
2
Fuel volume
fuel 0
0 = resettable
R/W*
EEPROM
U
32
0
..
9999
9999
m
3
03/04
80
/50h
2
Fuel volume
fuel 1
1 = resettable
R/W*
EEPROM
U
32
0..99999999
L
03/04
82
/52h
1
Number of faults
R
U16
0…65535
R
03/04
W 06/16
84
/54h
1
Preselected output in the event
communication with BACS breaks
down (fuel 0)
R/W*
EEPROM
U16
Fire rate
Modulating:
0…100%
Multistage:
1001…1003
Invalid:
32767
