Early SIB3s
with nuts on
threaded studs
securing the CAC3
Current SIB3s have screws
in nuts swaged into the board
to secure the CAC3
Figure 2-20 Mounting the CAC3 on the SIB3
Electronic Compartment Component Descriptions and Maintenance Procedures
2.3 System Controller Version 2.1 (SYSCON2.1)
Maxum II Reference Manual
50 Manual, 7/2017, 2000596-001
