International English 7. MICROMASTER 420 SPECIFICATIONS
100 MICROMASTER 420 Operating Instructions
6SE6400-5AA00-0BP0
230 V Three Phase MICROMASTER Inverters (unfiltered)
Order No. (6SE6420-2UC)
24-0CA0 25-5CA0
Input voltage range 3AC 200V - 240V +10% -10%
Motor output rating kW (hp) 4 (5) 5.5 (7.5)
Output KVA 7.7 9.6
Output current Max. A 17.5 22
Input current A 19.7 26.3
Input cable Min. mm
2
(awg) 2.5 (13) 4 (11)
Input cable Max. mm
2
(awg) 10 (7) 10 (7)
Output cable Min. mm
2
(awg) 2.5 (13) 4 (11)
Output cable Max. mm
2
(awg) 10 (7) 10 (7)
Dimensions [w x h x d] mm (inches) 185x245x195 (7.28x9.65x7.68) 185x245x195 (7.28x9.65x7.68)
Weight kg (lbs) 5.5 (12.1) 5.5 (12.1)
400 V Three Phase MICROMASTER Inverters (with built in Class A Filter)
Order No. (6SE6420-2AD) 22-2BA0 23-0BA0 24-0BA0 25-5CA0 27-5CA0 31-1CA0
Input voltage range 3AC 380V - 480V +10% -10%
Motor output rating kW (hp) 2.2 (3) 3 (4) 4 (5) 5.5 (7.5) 7.5 (10) 11 (15)
Output KVA 4.5 5.9 7.8 10.1 14 19.8
Output current Max. A 5.9 7.7 10.2 13.2 18.4 26
Input current A 7.5 10 12.8 17.3 23.1 33.8
Input cable Min. mm
2
(awg) 1 (17) 1 (17) 1.5 (15) 2.5 (13) 4 (11) 6 (9)
Input cable Max. mm
2
(awg) 6 (9) 10 (7)
Output cable Min. mm
2
(awg) 1 (17) 1.5 (15) 2.5 (13) 4 (11)
Output cable Max. mm
2
(awg) 6 (9) 10 (7)
Dimensions [w x h x d] mm (inches) 149x202x172 (5.87x7.95x6.77) 185x245x195 (7.28x9.65x7.68)
Weight kg (lbs) 3.1 (6.8) 3.3 (7.3) 3.3 (7.3) 5.4 (11.9) 5.7 (12.5) 5.7 (12.5)
400 V Three Phase MICROMASTER Inverters (unfiltered)
Order No. (6SE6420-2UD) 13-
7AA0
15-
5AA0
17-
5AA0
21-
1AA0
21-
5AA0
22-
2BA0
23-
0BA0
24-
0BA0
25-
5CA0
27-
5CA0
31-
1CA0
Input voltage range 3AC 380V - 480V +10% -10%
Motor output rating kW (hp)
0.37
(0.5)
0.55
(0.75)
0.75 (1) 1.1 (1.5) 1.5 (2) 2.2 (3) 3 (4) 4 (5) 5.5 (7.5) 7.5 (10) 11 (15)
Output KVA 0.9 1.2 1.6 2.3 3 4.5 5.9 7.8 10.1 14 19.8
Output current Max. A 1.2 1.6 2.1 3 4 5.9 7.7 10.2 13.2 18.4 26
Input current A 1.6 2.1 2.8 4.2 5.8 7.5 10 12.8 17.3 23.1 33.8
Input cable Min. mm
2
(awg) 1 (17) 1.5 (15) 2.5 (13) 4 (11) 6 (9)
Input cable Max. mm
2
(awg) 2.5 (13) 6 (9) 10 (7)
Output cable Min. mm
2
(awg) 1 (17) 1.5 (15) 2.5 (13) 4 (11)
Output cable Max. mm
2
(awg) 2.5 (13) 6 (9) 10 (7)
Dimensions [w x h x d] mm (inches)
73x173x149 (2.87x6.81x5.87)
149x202x172
(5.87x7.95x6.77)
185x245x195
(7.28x9.65x7.68)
Weight kg (lbs)
1.3 (2.9) 3.1 (6.8) 3.3 (7.3) 3.3 (7.3)
5.2
(11.4)
5.5
(12.1)
5.5
(12.1)
Notes
a) Siemens 4 pole-motor
b) 3 kW 230 unit requires an external choke (e.g. 4EM6100-3CB) and a 30 A mains
fuse to operate on a single phase supply.

Siemens MICROMASTER 420 Specifications

General

Power Range	0.12 kW to 11 kW
Output Voltage	0 to input voltage
Input Frequency	47 Hz to 63 Hz
Output Frequency	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds
Enclosure Rating	IP20
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Control Type	V/f control
Braking	Optional braking module
Protection Features	Overcurrent, overvoltage, undervoltage, overload, short circuit, ground fault
Cooling	Air-cooled
Ambient Temperature	-10 °C to +50 °C
Communication Interfaces	USS protocol
