7 MICROMASTER 420 Specifications
Table 7-1 MICROMASTER 420 Specifications
230 V Single Phase MICROMASTER Inverters (with built in Class A Filter)
Order No. (6SE6420-2AB) 11-2AA0 12-5AA0 13-7AA0 15-5AA0 17-5AA0 21-1BA0 21-5BA0 22-2BA0 23-0CA0
Input voltage range 1AC 200V - 240V +10% -10%
Motor output rating kW (hp) 0.12 (0.16) 0.25 (0.33) 0.37 (0.5) 0.55 (0.75) 0.75 (1) 1.1 (1.5) 1.5 (2) 2.2 (3) 3 (4)
Output KVA 0.4 0.7 1 1.3 1.7 2.4 3.2 4.6 6
Output current Max. A 0.9 1.7 2.3 3 3.9 5.5 7.4 10.4 13.6
Input current A 2 4 5.5 7.5 9.9 14.4 19.6 26.4 35.5
Input cable Min. mm
2
(awg)
1 (17) 2.5 (13) 4 (11)
6 (9)
Input cable Max. mm
2
(awg) 2.5 (13) 6 (9) 10 (7)
Output cable Min. mm
2
(awg) 1 (17) 1.5 (15)
Output cable Max. mm
2
(awg) 2.5 (13) 6 (9) 10 (7)
Dimensions [w x h x d] mm (inches) 73x173x149 (2.87x6.81x5.87) 149x202x172 (5.87x7.95x6.77) 185x245x195
(7.28x9.65x7.68)
Weight kg (lbs) 1.2 (2.6) 1.3 (2.9) 3.3 (7.3) 3.6 (7.9) 5.2 (11.4)
230 V Three Phase MICROMASTER Inverters (with built in Class A Filter)
Order No. (6SE6420-2AC) 23-0CA0 24-0CA0 25-5CA0
Input voltage range 3AC 200V - 240V +10% -10%
Motor output rating kW (hp) 3 (4) 4 (5) 5.5 (7.5)
Output KVA 6 7.7 9.6
Output current Max. A 13.6 17.5 22
Input current A 15.6 19.7 26.3
Input cable Min. mm
2
(awg) 2.5 (13) 2.5 (13) 4 (11)
Input cable Max. mm
2
(awg) 10 (7) 10 (7) 10 (7)
Output cable Min. mm
2
(awg) 1.5 (15) 2.5 (13) 4 (11)
Output cable Max. mm
2
(awg) 10 (7) 10 (7) 10 (7)
Dimensions [w x h x d] mm (inches) 185x245x195 (7.28x9.65x7.68)
Weight kg (lbs) 5.2 (11.4) 5.7 (12.5) 5.7 (12.5)
230 V Single/Three Phase MICROMASTER Inverters (unfiltered)
Order No. (6SE6420-2UC)
11-2AA0 12-5AA0 13-7AA0 15-5AA0 17-5AA0 21-1BA0 21-5BA0 22-2BA0 23-0CA0
Input voltage range 1/3AC 200V - 240V +10% -10%
Motor output rating kW (hp) 0.12 (0.16) 0.25 (0.33) 0.37 (0.5) 0.55 (0.75) 0.75 (1) 1.1 (1.5) 1.5 (2) 2.2 (3) 3 (4)
Output KVA 0.4 0.7 1 1.3 1.7 2.4 3.2 4.6 6
Output current Max. A 0.9 1.7 2.3 3 3.9 5.5 7.4 10.4 13.6
Input current A 0.7
(2 1AC)
1.7
(4 1AC)
2.4
(5.5 1AC)
3.1
(7.5 1AC)
4.3
(9.9 1AC)
6.2
(14.4 1AC)
8.3
(19.6 1AC)
11.3
(26.4 1AC)
15.6
(35.5 1AC)
Input cable Min. mm
2
(awg) 1 (17) 2.5 (13)
Input cable Max. mm
2
(awg) 2.5 (13) 6 (9) 10 (7)
Output cable Min. mm
2
(awg) 1 (17) 1.5 (15)
Output cable Max. mm
2
(awg) 2.5 (13) 6 (9) 10 (7)
Dimensions [w x h x d] mm (inches) 73x173x149 (2.87x6.81x5.87) 149x202x172 (5.87x7.95x6.77)
185x245x195
(7.28x9.65x7.68)
Weight kg (lbs) 1.2 (2.6) 2.9 (6.4) 2.9 (6.4) 3.1 (6.8) 5.2 (11.4)

Siemens MICROMASTER 420 Specifications

General

Power Range	0.12 kW to 11 kW
Output Voltage	0 to input voltage
Input Frequency	47 Hz to 63 Hz
Output Frequency	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds
Enclosure Rating	IP20
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Control Type	V/f control
Braking	Optional braking module
Protection Features	Overcurrent, overvoltage, undervoltage, overload, short circuit, ground fault
Cooling	Air-cooled
Ambient Temperature	-10 °C to +50 °C
Communication Interfaces	USS protocol
