5.3 System Parameters and Definitions
Parameter
Number
Parameter Name
Min
Max
[Default]
Units
♦
♦♦
♦P0003 User
Access Level
♦
♦♦
♦P0004 Setting
♦
♦♦
♦Changeable
♦
♦♦
♦Status
Drive Displayr0000
Displays the user selected output as defined in P0005.
Note:
Pressing the “Fn” button for 2 seconds allows the user to view the values of DC link
voltage, output current, output frequency, output voltage, and chosen r0000 setting (defined
in P0005).
-
-
[-]
-
1
7
Drive Stater0002
Displays the actual drive state.
Possible values:
0 “Commissioning Mode– (P0010 ≠ 0)”
1 “Ready to Run”
2 “Fault”
3 “Starting – DC Link Precharging”
4 “Running”
5 “Stopping – (ramping down)”
Note:
State 3 will only be visible while precharging DC Link and when externally powered
communications board is fitted.
0
5
[-]
-
2
7
User access levelP0003
Defines the access level into parameter sets. For most simple applications the default
(standard) setting is sufficient.
Possible Settings:
0 “User defined parameter list – see P0013 (Level 3) for details on use”
1 “Standard”: allows access into most frequently used parameters
2 “Extended”: allows extended access to inverter I/O functions
3 “Expert”: for expert use only.
4 “Service”: only for use by authorized service personnel –password protected.
0
4
[1]
-
1
All
'•'
