Siemens MICROMASTER 420 Operating Instruction

APPENDIX F International English
MICROMASTER 420 Operating Instructions 119
6SE6400-5AA00-0BP0
F - User Parameter Settings
Please enter your parameter settings in the following table.
Table E-1 User’s Parameters Settings
Parameter
Number
User
Settings
Default Parameter
Number
User
Settings
Default Parameter
Number
User
Settings
Default
r0000 - r0774 - P1300 1
r0002 - P0777 0 P1310 50
P0003 1 P0778 0 P1311 0
P0004 0 P0779 100 P1312 0
P0005 21 P0780 20 P1333 10
P0010 0 P0781 0 P1335 0
r0018 - P0918 3 P1336 250
r0021 - P0927 15 P1800 4
r0025 - r0947 i 0 - P1820 0
r0026 - r0947 i 1 - P1910 0
r0027 - r0947 i 2 - r1912 -
r0034 - r0947 i 3 - P2000 50
r0039 - r0947 i 4 - P2010 i 0 6
P0040 0 r0947 i 5 - P2010 i 1 6
r0052 - r0947 i 6 - P2011 i 0 0
r0053 - r0947 i 7 - P2011 i 1 0
r0056 - P0970 0 r2110 i 0 -
P0100 0 P1000 2 r2110 i 1 -
r0206 - P1001 0 r2110 i 2 -
r0207 - P1002 5 r2110 i 3 -
r0208 - P1003 10 r2197 -
P0300 1 P1004 15 P2200 0
P0304 *** P1005 20 P2201 0
P0305 *** P1006 25 P2202 10
P0307 *** P1007 30 P2203 20
P0308 0 P1016 1 P2204 30
P0309 0 P1017 1 P2205 40
P0310 50 P1018 1 P2206 50
P0311 0 P1031 0 P2207 60
P0335 0 P1040 5 P2216 1
P0340 0 P1058 5 P2217 1
P0350 *** P1059 5 P2218 1
P0611 100 P1060 10 r2224 -
P0614 100 P1061 10 P2231 0
P0640 150 P1080 0 P2240 10
P0700 2 P1082 50 r2250 -
P0701 1 P1120 10 P2253 0
P0702 12 P1121 10 P2257 1
P0703 9 P1130 0 P2258 1
P0704 0 P1131 0 r2260 -
r0722 - P1132 0 P2264 755
P0731 52:3 P1133 0 P2265 0
r0752 - P1134 0 r2266 -
r0754 - P1135 5 P2271 0
r0755 - P1200 0 r2272 -
P0756 0 P1210 1 r2273 -
P0757 0 P1215 0 P2280 3
P0758 0 P1216 1 P2285 0
P0759 10 P1217 1 P2291 100
P0760 100 P1232 100 P2292 0
P0761 0 P1233 0 r2294 -
P0771 21 P1236 0 P3900 0

Siemens MICROMASTER 420 Specifications

General

Power Range	0.12 kW to 11 kW
Output Voltage	0 to input voltage
Input Frequency	47 Hz to 63 Hz
Output Frequency	0 Hz to 650 Hz
Overload Capacity	150% for 60 seconds
Enclosure Rating	IP20
Input Voltage	200 V to 240 V (±10%), 380 V to 480 V (±10%)
Control Type	V/f control
Braking	Optional braking module
Protection Features	Overcurrent, overvoltage, undervoltage, overload, short circuit, ground fault
Cooling	Air-cooled
Ambient Temperature	-10 °C to +50 °C
Communication Interfaces	USS protocol
