Issue 08/03
MICROMASTER 440
6SE6400-5GA00-0BP0
Quick Start Guide 11
1 Mechanical Installation
1.1 Drilling Patterns and Dimensions
Frame Size A - Frame Size C
Figure 1-1 Drilling Pattern & Dimensions Frame Size A - Frame Size C
