Technical specifications
6.3 Derating data
Power Module PM330
Hardware Installation Manual, 12/2018, A5E32844552B AF
103
Derating factor of the output current as a function of the line voltage
Table 6- 10 Derating of the output current as a function of the line voltage, 380 V … 480 V 3 AC ±10 %
Rated power based on the
base-load current I
L
at 400 V.
Rated output current in A at a line voltage of
6SL3310-1PE34-6AA0 250 460 460 443 393 369
1)
Full rated current up to 440 V, therefore no derating for 415 V ±5 %.
Table 6- 11 Derating of the output current as a function of the line voltage, 500 V … 690 V 3 AC ±10 %
Rated power based on the
base-load current I
L
at 690 V.
Rated output current in A at a line voltage of
Derating of the output current as a function of the pulse frequency
With the factory setting, the drive starts with a 4 kHz pulse frequency, and under load,
automatically reduces the pulse frequency step-by-step to the frequencies required. When
the load decreases, the pulse frequency is increased automatically up to 4 kHz.
The values of the rated current refer to a pulse frequency of 2 kHz at 45° C ambient
temperature and are reached at any time by the automatic adaptation of the output pulse
frequency.
