Siemens PM330 User Manual

Appendix
A.4 Acceptance test/configuration test
Power Module PM330
Hardware Installation Manual, 12/2018, A5E32844552B AF
139
A.4.3
Documentation of the acceptance test
System or machine description
Designation
…
Type
…
Serial number
…
Manufacturer
…
End customer
…
Block diagram of the system or machine:
…
…
…
…
…
…
…
Inverter data
Table A- 6 Hardware version of the safety-related inverter
Name of the drive
Article number and hardware version of the inverter
…
…
…
…
Function table
Table A- 7 Active safety functions depending on the operating mode and safety equipment
Operating mode
Safety equipment
Drive
Selected safety function
Checked
…
…
…
…
…
…
…
…
Example:
Operation
Protective door closed
Fan
---
---
Protective door open
Fan
SS1-t (braking in 2 seconds)
Emergency Stop button active Fan STO
