Configuring with Web Based Management
5.4 "Information" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 03/2015, C79000-G8976-C267-08
113
Table 2 has the following columns:
●
Shows the available WLAN interfaces in this column.
●
Shows the port of the virtual access point.
●
Shows the MAC address of the virtual access point.
●
Shows the SSID.
●
Shows which authentication method is used.
If the authentication method "Open System + Encryption" or "Shared Key" is used,
"Encrypted (WEP/AES)" is displayed for both authentication methods.
●
Shows the status of the WLAN interface.
– enabled
The WLAN interface is enabled.
– disabled
The WLAN interface is disabled.
Client List
Logged-on clients
The page the clients logged on with the access point as well as additional information, for
example status, signal strength, MAC address.
Note
This tab is available only in access point mode.
