Configuring with Web Based Management
5.10 "iFeatures" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
290 Configuration Manual, 03/2015, C79000-G8976-C267-08
1. Select the "Enable iPCF" option for the required WLAN interface.
2. Click the "Set Values" button.
You configure the security settings in "Security > WLAN > Basic".
iPCF-MC
Requirements to be able to use iPCF-MC:
● The access point has at least two WLAN interfaces (dual AP).
● Access point mode: Only dual APs with KEY-PLUG W780 iFeatures (MLFB 6GK5 907-
8PA00)
● Client mode: Client with KEY-PLUG W740 iFeatures (MLFB 6GK5 907-4PA00)
● The management interface and data interface must be operated in the same frequency
band and mode and must match in terms of their wireless coverage. iPCF-MC will not
work if both wireless interfaces are equipped with directional antennas that cover different
areas.
● The management interfaces of all access points to which a client can change must use
the same channel. A client scans only this one channel to find accessible access points.
● Transmission based on IEEE801.11h (DFS) cannot be used for the management
interface. 801.11h (DFS) is possible for the data interface.
● The client cannot be operated with "Use Allowed Channel only".
● "Force roaming on Ethernet down" is automatically mirrored on the second interface.
When should iPCF-MC be used?
iPCF was developed to achieve short handover times when roaming between cells. The
iPCF-MC technique allows short handover times even for freely mobile clients and when a
lot of cells are involved or a large number of channels is being used.
iPCF and iPCF-MC are not compatible with each other and cannot be used at the same
time on a device.
With 11n devices, remember that the assignment of the WLAN interfaces is fixed for
iPCF-MC.
– WLAN1: Data interface
WLAN2: Management interface
