Siemens SCALANCE W780

Configuring with Web Based Management
5.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 03/2015, C79000-G8976-C267-08
211
●
Negotiation
Shows whether the automatic configuration is enabled or disabled.
●
MAC Address
Shows the MAC address of the port.
5.6.1.2
Configuration
Configuring ports
With this page, you configure the Ethernet ports of the device.
Note
SCALANCE W786-2 SFP
The two SFP ports of the SCALANCE W786
-2 SFP cannot be assigned parameters or
diagnosed individually.
Description
The table has the following rows:
●
"Port" drop-down list
Select the port to be configured from the drop-down list.
●
"Status" drop-down list
Specify whether the port is enabled or disabled.
– enabled
The port is enabled. Data traffic is possible only over an enabled port.
– disabled
The port is disabled.
●
Input box "Port Name"
Here, enter a name for the port.
