Configuring with Web Based Management
5.6 "Interfaces" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
Configuration Manual, 03/2015, C79000-G8976-C267-08
213
Changing the port configuration
Click the appropriate box to change the configuration.
Note
With various automatic functions, the device prevents or reduces the effect on other ports
and priority classes (Class of Service) if a port is overloaded. This can mean that frames are
discarded even when flow control is enabled.
Port overload occurs when
the device receives more frames than it can send, for example as
the result of different transmission speeds.
Follow the steps below to change the settings:
1. Change the settings according to your configuration.
2. Click the "Set Values" button.
