Configuring with Web Based Management
5.7 "Layer 2" menu
SCALANCE W780/W740 to IEEE 802.11n Web Based Management
252 Configuration Manual, 03/2015, C79000-G8976-C267-08
The page contains the following boxes:
●
Check box "Spanning Tree"
Enable or disable MSTP.
●
Drop-down list "Protocol Compatibility"
Select the compatibility mode of MSTP, for example if you select RSTP, MSTP behaves
like RSTP.
The following settings are available:
– STP
– RSTP
– MSTP
Note
If iPCF mode is enabled, only the
compatibility modes STP and RSTP are supported.
1. Select the "MSTP" check box.
2. From the "Protocol Compatibility" drop-down list, select the type of compatibility.
3. Click the "Set Values" button.
