Siemens SCALANCE X101-1 Commissioning Manual

Product Characteristics
4
4.1 Overview
Table 4-1 Overview of the product characteristics
Characteristics Device type
X101-1 X101-1FL X101-1LD X101-1POF
SIMATIC environment
+ + + +
Diagnostics LED
+ + + +
24V DC + + + +
Compact housing 40mm
(securing collar, etc.)
+ + + +
2x 24 V DC + + + +
Signaling contact + on-site operation
+ + + +
Diagnostics: Web, SNMP,
PROFINET
- - - -
C-PLUG
- - - -
Ring redundancy with RM
- - - -
Ring redundancy passive
+ + + +
Standby redundancy
- - - -
IRT capability
- - - -
Fast learning
- - - -
Passive listening
- - - -
Log table
- - - -
SNTP + SICLOCK - - - -
Cut through
+ + + +
Table 4-2 Overview of the possible attachments
Cable type/transceiver wavelength Device type, interface
X101-1 X101-1FL X101-1LD X101-1POF
TP(RJ-45)
1 1 1 1
Fiber multimode (BFOC) / 1300nm
1
Fiber multimode (BFOC) / 820nm
1
Fiber long distance monomode
(BFOC) /1310nm
1
Plastic optical fiber (SC-RJ) / 650nm
1
Industrial Ethernet Media Converters SCALANCE X-100 Series
Commissioning Manual, 07/2008, A2B00051521A
4-1
