Siemens SCALANCE X101-1

Product Characteristics
4.2 SCALANCE X101-1
4.2.10 SCALANCE X101-1 Technical Specifications
Technical Specifications of SCALANCE X101-1
Ports
Attachment of DTEs or network components over
twisted pair
1xRJ-45 socket with MDI-X pinning 100 Mbps
full duplex
Connection of further network components over
FOC
2 BFOC sockets
(100 Mbps, full duplex to 100 BaseFX)
Connector for power supply 1x4-pin plug-in terminal block
Connector for signaling contact 1x2-pin plug-in terminal block
Electrical Data
Power supply 2 x DC 24 V
(DC 18 - 32 V)
safety extra-low voltage (SELV)
Power loss at DC 24 V (typ.) 3 W
Current consumption at rated voltage (typ.) 120 mA
Minimum rated current of the power supply 170 mA
Overvoltage protection at input PTC resettable fuse (0.5 A / 60 V)
Permitted Cable Lengths
Network span parameter/TP cable length
0 – 100 m
0 – 85 m
IE FC TP standard cable with IE FC RJ-45
plug 180
or
IE FC outlet RJ-45 with IE FC TP standard cable
(0 - 90 m) + 10 m TP cord
IE FC TP marine/trailing/flexible with IE FC RJ-45
plug 180
or
IE FC TP marine/trailing/flexible (0 – 75 m) + 10
m TP cord over IE FC outlet RJ-45
Network span parameter/FO cable length
0 - 3000 m
Glass FOC
62.5/125 µm or 50/125 µm glass fiber;
≤ 1 dB/km at 1300 nm;
1200 MHz x km at 1300 nm;
6 dB max. permitted FO cable attenuation with 3
dB link power margin
Bending radius once without tensile force:
100 mm
bending radius repeatedly with tensile force:
150 mm
Industrial Ethernet Media Converters SCALANCE X-100 Series
Commissioning Manual, 07/2008, A2B00051521A
4-11
