Product Characteristics
4.2 SCALANCE X101-1
Transparent link display (green LED)
“TL” (transparent link) LED:
Status Meaning
Lit green Transparent link parameterized.
Not lit Stand-alone mode. DTEs are connected to both ports of the
media converter (no cascading)
See chapter 4.2.8 "Important notes"!
Industrial Ethernet Media Converters SCALANCE X-100 Series
4-10 Commissioning Manual, 07/2008, A2B00051521A
