Product Characteristics
4.5 SCALANCE X101-1POF
Note
The link state of port P1 and port P2 (LED lit green) in stand-alone-mode is only indicated if
both ports have link at the same time.
In transparent link mode the link state is also recognized and indicated by the optical
port(P2) without a link at the port P1 (see chapter 4.5.8).
Transparent link display (green LED)
“ TL” (transparent link) LED:
Status Meaning
Lit green Transparent link parameterized.
Not lit Stand-alone mode. DTEs are connected to both ports of the
media converter (no cascading)
See chapter 4.5.8 "Important notes"!
Industrial Ethernet Media Converters SCALANCE X-100 Series
4-46 Commissioning Manual, 07/2008, A2B00051521A
