Technical specifications
6.2 Technical Specifications - CloudConnect 716
SIMATIC CC7
Operating Instructions, 10/2019, C79000-G8976-C503-02
127
Technical specifications - CloudConnect 716
Cable cross-section connectable to
the terminal block
• Without wire end ferrule
• With wire end ferrule
• With TWIN wire end ferrule
• 0.2 .. 2.5 mm
2
/ AWG 24 .. 13
• 0.25 .. 1.5 mm
2
/ AWG 24 .. 16
• 0.5 .. 1.0 mm
2
/ AWG 20 .. 17
Further electrical data
Current consumption (typical) 250 mA
Effective power loss (typical) 6 W
Overvoltage category according to
IEC / EN 60664-1
Category II
Digital input
Quantity
1 x terminal block (DI)
Design
2-pin
Voltage Rated voltage 24 V DC Safety Extra Low Voltage (SELV)
• For state "1": 13 to 30 V DC
• For state "0": -30 to 3 V DC
Other properties
• Maximum input current 8 mA
• Maximum cable length < 30 m
Cables should be routed in pairs
• Input isolated from electronics
• Minimum pulse length: 100 ms
Digital output
Quantity
1 x terminal block (DO)
Design
Switch, 2-pole
Voltage
Rated voltage 24 V DC Safety Extra Low Voltage (SELV)
Other properties
• Internal, not current-limited
• Maximum current-carrying capacity 1 A
• Maximum cable length < 30 m
Cables should be routed in pairs
• Output isolated from electronics
Terminal blocks (power supply, digital input, digital output)
Clamping screw M2
Screwdriver blade:
0.4...2.5 (DIN 5264)
Tightening torque
0.2...0.25 Nm
Connectable cable cross-sections
• Without wire end ferrule
• With wire end ferrule
• 0.5...2.5 mm
2
/ AWG 20...12
• 0.5....1.5 mm
2
/ AWG 20 .. 16
Permitted ambient conditions
Ambient temperature During operation with the rack in-
stalled horizontally
0 °C ... +60 °C
During operation with the rack in-
stalled vertically
0 °C ... +50 °C
During storage
-40 °C ... +70 °C
