Configuration
4.7 Process access
SIMATIC CC7
Operating Instructions, 10/2019, C79000-G8976-C503-02
63
4.7 Process access
4.7.1 Station configuration
Add station
Here you create new process stations as communication partners.
●
Station name
To create a new station, enter a unique name in the input box.
●
Add
Creates a new station with the previously entered name in the configuration data of the
gateway.
Station configuration
● Select station
Select one of the created stations to configure its settings.
●
Protocol
Select the protocol type for the selected station:
– S7 Ethernet
– S7 PROFIBUS
– Modbus/TCP
After selecting the protocol, click on the tab "S7 Ethernet", "S7 PROFIBUS" or
"Modbus/TCP". The configurable parameters for this station are displayed.
●
Delete station
By clicking the button, the selected station is deleted.
Note
Accidental deletion
If you accidentally delete a station, you cannot undo the
deletion.
S7 Ethernet
The gateway and the SIMATIC S7 station communicate over S7 connections. The
connection type is TCP. The gateway is the active partner during connection setup.
