Technical specifications
6.2 Technical Specifications - CloudConnect 716
SIMATIC CC7
126 Operating Instructions, 10/2019, C79000-G8976-C503-02
Technical specifications - CloudConnect 712
Design, dimensions and weight
Module format Compact module S7-1500
Degree of protection
IP20
Weight
300 g
Dimensions (W x H x D) 35 x 147 x 127 mm
Mounting type
• 35 mm DIN rail mounting
• S7-300 standard rail mounting
• S7-1500 standard rail mounting
• Wall mounting
For further data, refer to section Application and functions (Page 11).
6.2 Technical Specifications - CloudConnect 716
Technical specifications - CloudConnect 716
Article number
6GK1411-5AC00
Attachment to Industrial Ethernet
Quantity
2 x gigabit interface (P1, P2)
Design
RJ-45 jack, galvanically isolated
Properties
• Standard
• Transmission speeds
• Other properties
• 1000BASE-T, IEEE 802.3ab
• 10 / 100 / 1000 Mbps
• Half duplex/full duplex, autocrossover, autonegotiation, autosensing
Connection to PROFIBUS
Quantity
1 x PROFIBUS/MPI interface (MPI/DP)
Design and standard
9-pin D-sub socket, RS-485
Transmission speeds 9.6 kbps, 19.2 kbps, 45.45 kbps,
93.75 kbps, 187.5 kbps, 500 kbps,
1.5 Mbps, 3 Mbps, 6 Mbps, 12 Mbps
Maximum current consumption on
the PROFIBUS interface when con-
necting network components (for
example, optical network compo-
nents)
15 mA at 5 V (only for bus termination)
*
Power supply
Design Socket including 5-pin terminal block with reverse polarity protection
Power supply
• Type of voltage
• Permitted low limit
• Permitted high limit
• 24 V DC
• 19.2 V
• 28.8 V
