Specifications
6.5 Interface assignment Terminal Box DP
Mobile Panel 177 (WinCC flexible)
6-12 Operating Instructions (Compact), Edition 07/2005
6.5 6.5 Interface assignment Terminal Box DP
Position of the ports
Figure 6-10 Position of the ports
① Terminal strip 1
② Fast connector
③ Terminal strip 2
Caution
When connecting the cables to the terminal strips ensure that the assignments for Terminal
strips 1 and 2 are not reversed.
