10-3
OP27,
OP37 Equipment Manual
Release 05/99
Figure
10-2 illustrates the structure of a line for the SIMA
TIC S5 in the form
of an example:
Operand value
Data format
Operand address
(for data types DB, DW, DB, DD:
Number of DW or DD)
DB number
(applicable only to data types DB,
DW, DB and DD)
Data type
34 KF28 20DB, DW
Figure 10-2 Display of PLC operands for the SIMATIC S5
Figure
10-3 illustrates the structure of a line for the SIMA
TIC S7 in the form
of an example:
Operand value
Data format
Operand address
(for data types DBB, DBW DB,
DBD and DB: Number of DB, DD)
DB number
(applicable only to data types DBB,
DBW, DBD and DBX)
Data type
MPI address
PLC address input
1438 DEC12
1820
DB, DBD001
Figure 10-3 Display of PLC operands for the SIMATIC S7
Operands
for
SIMA
TIC S5
Operands for
SIMA
TIC S7
Status/Force T
ag Using the OP
