Siemens simatic hmi op27 User Manual

12-4
OP27, OP37 Equipment Manual
Release 05/99
ActionStep
3
Working from the rear, tighten the grub screws Ë against the front panel,
as illustrated.
Rear of OP
Grub screw Ë
Hexagon socket-head screw key
Screwtype clamps
Note:
 Make sure the seal is seated correctly against the front panel.
 Do not overtighten the screws.
Mechanical Installation
