18-13
OP27,
OP37 Equipment Manual
Release 05/99
4. Use
the four screws supplied
¸
to secure the control panel interface to the
OP (see Figure 18-10).
¸
¸
¸
¸
Figure 18-10 Securing the control panel interface to the OP (example OP37)
Remove
in the reverse sequence of the installation procedure.
Options
