D-10
OP27,
OP37 Equipment Manual
Release 05/99
Remedy:CauseMessage
636 Event message is not configured Configure
event message (–> message num
-
ber) fully.
640 Alarm message is not configured
Configure alarm message (–> message
number).
645 Internal error
PLC co-ordination area not receivable during startup.
Press key to restart.
If the fault is not corrected by performing a
restart, please contact the SIMATIC Hot-
line.
649 Internal error
Driver number configured can not be interpreted.
If the fault is not corrected by performing a
restart, please contact the SIMATIC Hot-
line.
650 Missing area pointer. Configure an area pointer.
653 The configured user version number does not match the
version number stored on the PLC.
Change configuration and retransfer.
655 PLC acknowledgement area does not physically follow
on from the alarm messages area (–> no startup).
657 Configured PLC protocol is not possible. Use current firmware version or configure
different protocol.
667 Configuration error:
Variable x:
1 Data type is not DB
2 DB number is greater than 15
3 DB length is greater than 1024
4 DW is in data block header
5 Actual value not in send block
6 Setpoint not in receive block
7 Setpoint/actual value not in receive block
8 Initial value not in send block
9 Data type is not DB
10 DB number is greater than 15
11 DB length is greater than 1024
12 DW is in data block header
13 Area is in wrong DB
14 Sum of data blocks too great
x = 1..8: Change the configuration of the
process link and retransfer.
x = 9..13:Change configuration of area
pointer and retransfer
x = 14: Restrict configuration and re-
transfer.
668 Incorrect configuration.
Meaning of variables:
1: Incompatible PLC types configured
2: No PLC configured
3: Incorrect baud rate configured
Change configuration and retransfer.
669 Too many actual values (> 512) have been configured for
cyclic reading in a screen/variable.
670 Too many variables requested simultaneously. Lengthen standard clock pulse or configure
fewer variables on screen.
671 Configuration of message variables incompatible. Differ-
ences between configuration and PLC.
Check S7 programs,
check message server configuration,
