2-2
OP27, OP37 Equipment Manual
Release 05/99
OP37OP27Functions
Message acquisition
Time of occurrence Date and time
Message events Arrive, depart, acknowledge
Screens
View
4
Printout
4
Static screen elements Pixel graphics
Text
Character graphics
Input/output elements Numeric/alphanumeric input fields
Numeric/alphanumeric output fields
Combined input/output fields
Symbolic text input fields
Symbolic text/graphics output fields
Bar graphs
Trends
Operator prompting Icons for soft key functions
Fixed window
4
Limit value monitoring Inputs/outputs
4
Conversion functions Inputs/outputs
4
T ext attributes
Display Flashing, inverse, underscore
Printer (messages) Bold, italic, underscore
Help text
Lines/characters 7/35
For messages
4
For input fields
4
For screens
4
Print functions Hardcopy of screen contents
(screen dump)
4
 character mode (ASCII)
 graphics mode
4
4
Direct message logging
4
Print screen lists in

character mode (ASCII)
4

c
h
arac
t
er mo
d
e
(ASCII)
 graphics mode
4
4
Password pr otection Number of passwords
Password levels
50
10 (0...9)
Functionalty
