The settings configured for printer type and printer parameters can be modified
online via the symbolic input fields:
 with the OP27 on standard screens General Printer Settings , Print Scr een
and Assign Color (Figure 7-1).
 with the OP37 on standard screen Printer Settings (Figure 7-2).
Make sure that the parameters on the OP37 comply with those of the printer .
General Printer Settings
Printer:
Interface:
Baud rate:
Data bits:
Stop bits:
Timeout:
Parity:
Type:
Print Screen:
Printout:
Color:
Bold:
Density:
Needles:
Color Assignment
OP (-)
OP (-)
Printer Printer
(0) Black:
(1) Blue:
(2) Green:
(3) Cyan:
(4) Red:
(5) Magenta:
(6) Yellow:
(-1) White:
( Value -1 = No color" )
Figure 7-1 Standard screens for printer settings (example OP27)
Standard screen
Printing
