7-3
OP27, OP37 Equipment Manual
Release 05/99
(0) Black
(1) Blue:
(2) Green:
(3) Cyan:
(6) Y ellow:
(5) Magenta:
(4) Red:
(–1) White:
Hardcopy:
Printout:
Color:
Bold:
Density:
Matrix prt.:
OP Printer OP<–> Printer<–>
Color Assignment
( V alue –1 = “no color” )
Printer Settings
ESC
General:
Interface:
Baud
rate:
Data bits:
Stop bits:
T imeout (s):
Parity:
Type:
Printer:
Figure 7-2 Standard screen for printer settings (example OP37)
Interface Set printer interface:
 IF2 (serial)
 LPT (parallel, OP37 only)
T ransfer Parameters Standard setting (serial):
 BAUD RATE: 9600
 DATA BITS: 8
 STOP BITS: 1
 PARITY: None
 TIMEOUT (S): 60
Do not change the parameters unless they do
not correspond to the transfer parameters of the
printer.
Printer Select a printer from the list of configured
printers.
Meaning of
operating elements
Printing
