8-4
OP27,
OP37 Equipment Manual
Release 05/99
ESC
Data
Record Processing
Recipe:
Data
record name:
Comment:
Data medium:
Sort order:
Format
Figure 8-2 Input fields and soft keys in the standard screen Data Record Processing
(example: OP37)
Copy
current values from the PLC to the main memory of
the OP and save them as a data record on one of the fol
-
lowing data media:
OP27 OP37
flash
module (memory card)
flash
module (memory card)
disk
Load selected data records from data medium to the main
memory of the OP and transfer from there to the PLC.
Delete selected data record on the data medium.
Create and modify selected data record on the data
medium.
Select data record from recipe data.
ESC
Exit from standard screen
Meaning of
operating elements
Recipes
