8-5
OP27,
OP37 Equipment Manual
Release 05/99
Recipe Select
a recipe from the list of configured recipes.
Data r
ecord
name
Enter or select the name of the new data record or the data
record to be edited.
Comment
Enter a comment in respect of the data record to be edited.
The comment entered is only accepted when the data
record is stored on the data medium. It is not accepted if
the data record is saved a second time. In this case, the
comment must be entered in the Edit window (refer to Fig
-
ure 8-4 on Page 8-10).
Sort order
Define the sorting criteria for the list of data records. Select
from the following sorting criteria:
unsorted,
alphabetic,
alphabetic reversed,
chronological,
chronological reversed.
Data medium
Select one of the following data media:
OP27 OP37
flash
module (memory card)
flash
module (memory card)
disk
Format the data medium using the
Format
list box.
Current values can be downloaded from the OP to the PLC and vice versa,
without having to store them on a data medium. This makes the startup phase
of a process easier
, for example. Similarly
, transfer between the OP and data
medium is also possible.
Using the standard screen
Selection Data Recor
d T
ransmissions
(Figure 8-3) it
is possible to
transfer the current values from the PLC to the main memory of the OP
,
transfer the current values from the main memory of the OP to the PLC,
load data records from data medium into the main memory of the OP
,
Selection Data Record T
ransmissions from the main memory of the OP to a
data medium.
Standard
screen
Selection Data Re
-
cord Transmission
Recipes
