Siemens SIMATIC Ident RF200 User Manual

Command and message frames
2.3 "WRITE" command
ASCII protocol for RF200
Operating Manual, 11/2016, C79000-G8976-C329-04
11
Address
Designation
Value
Description
Byte 6
User data address
--
Value from command
Byte 7 --
Byte 8
User data address
--
Value from command
Byte 9 --
Byte 10
User data length
--
Value from command
Byte 11
--
Byte 12
User data
lowest byte, high nibble
max. 248 bytes net data (496
bytes)
Byte 13
lowest byte, low nibble
...
...
Byte n-1
highest byte, high nibble
Byte n
highest byte, low nibble
2.3
"WRITE" command
Table 2- 4 "WRITE" command
Address
Designation
Value
Description
Byte 0
Frame length
high nibble
Net data length of the frame - 1
byte
(depending on data length)
Byte 1 low nibble
Byte 2
Command
0x30
--
Byte 3
0x31
Byte 4
Status
0x30
--
Byte 5
0x30
Byte 6
User data address
0x30
The max. permitted address corre-
sponds to the memory size -1 byte
Infineon: 0x30, 0x33, 0x44, 0x46
NXP: 0x30, 0x30, 0x36, 0x46
Fujitsu: 0x30, 0x37, 0x43, 0x46
TI, ST.: 0x30, 0x30, 0x46, 0x46
Byte 7
high byte, low nibble
Byte 8 low byte, high nibble
Byte 9 low byte, low nibble
Byte 10
User data length
high nibble
Length of user data to be written:
min: 0x30, 0x31
max: 0x46, 0x38
Byte 11 low nibble
Byte 12
User data
lowest byte, high nibble
max. 248 bytes net data (496
bytes)
Byte 13
lowest byte, low nibble
...
...
Byte n-1
highest byte, high nibble
Byte n
highest byte, low nibble
