Siemens SIMATIC Ident RF200 User Manual

Command and message frames
2.4 SLG STATUS (mode 0) command
ASCII protocol for RF200
12 Operating Manual, 11/2016, C79000-G8976-C329-04
Table 2- 5 "WRITE" acknowledgment
Address
Designation
Value
Description
Byte 0
Frame length
0x30
Net data length of the frame - 1
byte
Byte 1 0x32
Byte 2
Command
0x30
--
Byte 3 0x31
Byte 4
Status
high nibble
Error code “error_Moby”
Byte 5
low nibble
2.4
SLG STATUS (mode 0) command
Table 2- 6 “SLG STATUS” (mode 0) command
Address
Designation
Value
Description
Byte 0
Frame length
0x30
Net data length of the frame - 1
byte
Byte 1
0x36
Byte 2
Command
0x30
--
Byte 3
0x34
Byte 4
Status
0x30
--
Byte 5
0x30
Byte 6
Mode
0x30
Mode 0
Byte 7
0x30
Byte 8
Reserve
0x30
--
Byte 9
0x30
Byte 10
Reserve
0x30
--
Byte 11
0x30
Byte 12
Reserve
0x30
--
Byte 13
0x30
Table 2- 7 "SLG STATUS" (mode 0) acknowledgment
Address
Designation
Value
Description
Byte 0
Frame length
0x30
Net data length of the frame - 1
byte
Byte 1
0x35
Byte 2 Command 0x30 --
Byte 3
0x34
Byte 4
Status
high nibble
Error code "error_Moby"
Byte 5
low nibble
Byte 6
S-Info
0x30
Mode from command
Byte 7
0x30
