Siemens SIMATIC Industrial Flat Panel IFP1500

Technical information
7.5 Technical specifications
Industrial Flat Panel IFP1500, IFP1900, IFP2200
88 Operating Instructions, 06/2014, A5E31298376-AB
Testing mechanical ambient conditions
The table below provides information on the type and scope of tests for mechanical ambient
conditions.
Tested for
Test standard
Comments
Vibrations Vibration test in accordance
with IEC 60068, part 2–6
(sinusoidal)
Type of vibration:
Frequency cycles at a rate of change of 1
octave/minute.
5 Hz ≤ f ≤ 8.4 Hz, constant amplitude 3.5 mm
8.4 Hz ≤ f ≤ 150 Hz, constant acceleration 1 g
Vibration duration:
10 frequency cycles per axis in each of the three
mutually vertical axes
Shock Shock test in accordance
with IEC 60068, Part 2 –27
Type of shock: Half-sine
Severity of shock:
Peak value 15 g, duration 11 ms
Direction of shock:
3 shocks in ± direction of axis in each of the
three axes vertical to each other
Climatic ambient conditions
The following table shows the climatic ambient conditions for operation of the device.
Ambient conditions
Permitted range
Comments
Temperature:
Vertical mounting
Mounting at an angle
From 0 to 50 °C (horizontal)
1
From 0 to 40 °C (vertical)
From 0 to 40 °C (horizontal)
From 0 to 35 °C (vertical)
Slope angle max. 35°
Relative humidity
10 to 90%, without condensation
Atmospheric pressure 1 080 to 795 hPa Corresponds to an elevation of -
1000 m to 2000 m
Pollutant concentration SO
2
: < 0.5 vpm;
Relative humidity <60%, no
condensation
Test: 10 cm
3
/m
3
; 10 days
H
2
S: < 0.1 vpm;
Relative humidity <60%, no
condensation
Test: 1 cm
3
/m
3
; 10 days
1
IFP1900 and IFP2200: From 0 to 45° C
