Siemens SIMATIC Industrial Flat Panel IFP1500

Installing and connecting the device
3.2 Mounting the device
Industrial Flat Panel IFP1500, IFP1900, IFP2200
Operating Instructions, 06/2014, A5E31298376-AB
35
Device
Position
Touch/key device
with:
• 15" display
3.2.3
Fastening the device with mounting clamps or latch fasteners
Requirement
● All packaging components and protective films have been removed from the device.
● The mounting clamps included in the accessory kit are ready to hand.
Procedure
Note
If the mounting seal is damaged or p
rotrudes over the device, the degree of protection is not
guaranteed.
