Installing and connecting the device
3.2 Mounting the device
Industrial Flat Panel IFP1500, IFP1900, IFP2200
Operating Instructions, 06/2014, A5E31298376-AB
33
Mounting the device
3.2.1
Before installing the device, please ensure that the installation location complies with the
following:
The device is classified for use as "Open Type" according to UL508 in the Industrial Control
Equipment sector. In the event of overheating, the device may discharge burning materials
that can cause a fire.
Keep in mind:
• Requirement for approval and operation of the device according to UL508 is its
installation in a UL508-compliant enclosure.
• Install the device in an enclosure that meets the requirements of paragraphs 4.6 and
4.7.3 of the standards IEC/UL/EN/DIN-EN 60950-1.
● Ensure that the protective contact socket of the building installation is easily accessible
and that there is a mains disconnect switch in switchgear cabinet installations.
● Position the device so that it is not exposed to direct sunlight.
● Position the device so that it is easily accessible for the operator.
● Choose a suitable installation height.
● Ensure that the air vents of the device are not covered as a result of installation. Note the
permitted mounting positions.
