Siemens SIMATIC IPC477E PRO User Manual

Technical specifications
9.4 Technical specifications
SIMATIC IPC477E PRO
Operating Instructions, 08/2017, A5E39912462-AA
123
15" display
15"
Display type
LCD TFT
Active display area 348 x 197 mm
Resolution
1366 x 768 pixels
Possible colors
Up to 16.7 million
Brightness control Yes, value range 0 to 99
0 = backlighting off
Backlighting
Half Brightness Life Time (MTBF
1
)
LED
50000 h
Pixel error class in accordance with ISO 9241-307
II
Touch force capacitive multi-touch screen
With test pen, 2 mm diameter: 5 N
1
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the
original value. MTBF is increased by using the integrated dimming function, for example time-
controlled via screen saver or centrally via PROFIenergy.
19" display
19"
Display type
LCD TFT
Active display area
410 x 230 mm
Resolution
1366 x 768 pixels
Possible colors
Up to 16.7 million
Brightness control Yes, value range 0 to 99
0 = backlighting off
Backlighting
Half Brightness Life Time (MTBF
1
)
LED
50000 h
Pixel error class in accordance with ISO 9241-307
II
Touch force capacitive multi-touch screen
With test pen, 2 mm diameter: 5 N
1
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the
original value. MTBF is increased by using the integrated dimming function, for example time-
controlled via screen saver or centrally via PROFIenergy.

Siemens SIMATIC IPC477E PRO Specifications

General

Brand	Siemens
Model	SIMATIC IPC477E PRO
Category	Industrial PC
Language	English
