Siemens SIMATIC IPC477E PRO User Manual

Technical specifications
9.4 Technical specifications
SIMATIC IPC477E PRO
124 Operating Instructions, 08/2017, A5E39912462-AA
22" display
22"
Display type
LCD TFT
Active display area 475 x 267 mm
Resolution
1920 x 1080 pixels
Possible colors
Up to 16.7 million
Brightness control Yes, value range 0 to 99
0 = backlighting off
Backlighting
Half Brightness Life Time (MTBF
1
)
LED
30000 h
Pixel error class in accordance with ISO 9241-307
II
Touch force capacitive multi-touch screen
With test pen, 2 mm diameter: 5 N
1
MTBF: Operating hours after which the maximum brightness is reduced by half compared to the
original value. MTBF is increased by using the integrated dimming function, for example time-
controlled via screen saver or centrally via PROFIenergy.
Interfaces
COM 1 / COM 2
RS 232, max. 115 Kbps, 9-pin, D-sub plug
2 x DisplayPort (DPP)
Connection of display devices with DisplayPort connection
Keyboard
Connection via USB port
Mouse
Connection via USB port
USB Back of device:
• 4 × USB 3.0
• Max. 2 high-current ports can be operated simultaneously
• Max. 5 W for all USB devices
Ethernet
1
3 × RJ45 connection, Intel 1 x I219LM, 2 x I210
10/100/1000 Mbps, electrically isolated, teaming-capable
2
1
For unique labeling, the Ethernet ports are numbered on the enclosure. The numbering by the
operating system can differ.
2
Teaming can be set and initiated in the configuration interface. In teaming operation, jumbo
frames, e.g. for the camera application, are not supported.
