Service and maintenance
11.1 Removing and installing hardware components
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
101
How to remove the power supply unit
6. Remove the identified retaining screws.
7. Pull the power supply unit towards the front
(1) and lift it out of the device (2).
1
2
