Description
3.4 Function
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
15
3.4 Function
● Integrated programmable monitoring functions (program execution (watchdog), internal
housing temperature, fan speed)
● Enhanced diagnostic/messaging via Ethernet, E-mail, SMS, and for direct input in
SIMATIC software via OPC (optional using SIMATIC IPC DiagMonitor):
– Operating hours counter
– Hard disk status
– System status (heartbeat)
– Automatic logging of all messages to a log file
– Option of remote monitoring of networked SIMATIC IPCs
● RAID1 (mirroring) for automatic data mirroring of two serial ATA hard drives
3.5 Features
General features
Design
19" rack, 2 HU
Rugged panel-mount housing, all metal
Prepared for mounting telescopic rails
Can be mounted horizontally
Lockable front cover as access protection
Enclosure
Dust protection by means of overpressure ventilation using
bearing-seated front fan via filter
Enclosure cover fastened with a single screw
Front fan can be exchanged without tools
Card retainer for reliable operation of PC modules under
vibration and shock conditions
Drive bays
Front 2 x low profile removable rack
or
2 x 3.5" (in vibration damped drive rack)
1 x optical drive (slimline)
Slots for expansion cards long
2x PCI or 1x PCI, 1x PCIe x4
1x PCIe x16
1)
