Detailed descriptions
16.5 BIOS Setup
SIMATIC IPC647C
182 Operating Instructions, 12/2010, A5E02669337-02
16.5.5 Advanced menu
Menu layout
Figure 16-5 "Advanced" menu (example)
Settings in the Advanced Menu
Entry Meaning
Peripheral Configuration Configuration of components on the
motherboard.
SATA Configuration Configuration of the SATA interface.
Video Configuration Configuration of the graphics interface
USB Configuration Configuration of the USB ports
Chipset Configuration Extended chipset configuration.
CPU Configuration Configuration of CPU parameters
Active Management Technology Support Configuration of the AMT functionality
Fan control Activate/deactivate fan control. If deactivated, the
fan always runs at full speed.
Operating Mode Switch Select operating mode switch
(optional, depending on version)
