Detailed descriptions
16.5 BIOS Setup
SIMATIC IPC647C
Operating Instructions, 12/2010, A5E02669337-02
183
Advanced menu > "Peripheral Configuration"
Figure 16-6 "Peripheral Configuration" submenu example
Entry Meaning
Internal COM 1 Enable (Enabled) or disable (Disabled) the serial port or
configure it automatically (Auto)
With Enabled, it is possible to specify the I/O base address and
the interrupt.
AUTO: BIOS switches on the COM. Resources are assigned in
the OS per reconfiguration.
Onboard Ethernet 1: Enable or disable the onboard Ethernet 1 interface.
Ethernet 1 Address: Display the MAC address of Ethernet 1
Onboard Ethernet 1: Enable or disable the onboard Ethernet 2 interface.
Ethernet 1 Address: Display the MAC address of Ethernet 2
PCI – MPI / DP or PROFINET: Enable or disable the onboard MPI/DP or PROFINET interface.
