Integration into an automation system
8.2 PROFINET
SIMATIC IPC647C
56 Operating Instructions, 12/2010, A5E02669337-02
SIMATIC NET
You can create, operate and configure SIMATIC installations using this software package.
You will find this information on the SIMATIC NET Manual Collection CD. The software
package and the documentation are not parts of the development package.
Additional information
You can find additional information in the catalog and the Siemens online ordering system:
Industrial Automation and Drive Technologies (
3http://mall.automation.siemens.com).
For Development Kit DK-16xx PN IO see Development Kit DK-16xx PN IO
(
3http://www.automation.siemens.com/net/html_00/produkte/040_cp_1616_devlopkit.htm)
8.2 PROFINET
CP 1616 onboard
The basic characteristics of the PCS 1616 onboard are:
● Optimized for PROFINET IO
● With Ethernet realtime ASIC ERTEC 400
● Three RJ45 sockets for connecting terminal devices or addition network components
● Integrated 3-port real-time switch
● Automatic hardware detection
CAUTION
Only one CP 1616 can be installed in a PG/PC. If you want to use an additional CP
1616 module, the "CP 1616 onboard" option must be disabled in the BIOS Setup.
