Commissioning
7.4 Notes on operation
SIMATIC IPC647C
46 Operating Instructions, 12/2010, A5E02669337-02
The table below shows the assignment of the removable rack positions in the device to the
RAID system reports:
Assigned LED
1)
RAID BIOS RAID software SATA
interface
Installation location Enclosure
labeling
HDD1 ALARM Port 0 Device Port 0 SATA0
③ Removable rack
1
HDD2 ALARM Port 2 Device Port 2 SATA2
④ Removable rack
2
1)
If the SIMATIC monitoring software is installed, the status LED ⑤ or ⑥ on the front panel
is lit if the hard disk has failed.
Replacing a hard disk
Check which hard disk has been reported as faulty by the RAID controller (hard disk on
channel 1 or 2) and replace the hard disk as described in section .
Information about the recovery of the RAID system is available in the section
2RAID system
(Page
247).
7.4.4 2HDD system (optional)
When the device ships, the second hard disk is connected to SATA port 2. This hard disk
drive is not set up. This gives you the option of backing up your data to this hard disk. For
information on hard disk capacities, refer to your order documentation.
Booting from the slave hard disk
In order to allow booting from the second hard disk, you need to configure it as the primary
boot device. Make the following settings in your BIOS Setup:
Select Boot > Hard Drive > <Disk name> e.g. STxxxxxxxxx- SATA2, then press the "+" key
to move it up in the boot order.
NOTICE
The drive letters for the partitions on both drives are assigned by the operating system
used. You can change these in the Control Panel as required.
