Description
3.5 Features
SIMATIC IPC647C
16 Operating Instructions, 12/2010, A5E02669337-02
General features
Graphics
Onboard Intel® CPU with integrated
HD Graphic Controller and Intel® QM57 Express Chipset
Platform Controller Hub, 2-D and 3-D engine integrated on
the processor
Dynamic Video Memory Technology
(uses up to 1.7 GB of RAM)
Up to 1600x1200 at 120 Hz / 32-bit color depth
Max. resolution:
VGA 2560x1600 at 60 Hz / 32-bit color depth
DVI 2048x1152 at 60 Hz / 32-bit color depth
in PCIe x16 slot (optional)
PCIe x16 graphics card (dual head: 2x DP, 2x VGA or
2x DVI-D through DP adapter),
256 MB memory at 75 Hz / 32-bit color depth
Maximum resolution:
DP 2560x1600 at 60 Hz / 32-bit color depth
DVI 1920x1200 at 60 Hz / 32-bit color depth
VGA 2048x1536 at 60 Hz / 32-bit color depth
Interfaces
PROFIBUS/MPI
12 Mbps (isolated potential, compatible to CP 5611); optional
PROFINET 10/100 Mbps (CP 1616 onboard), three RJ-45; optional
Ethernet 2x 10/100/1000 Mbps (two RJ-45)
Wake on LAN and Remote Boot supported
USB 2 x front panel, 4 x rear panel, 1 x internal; (high current)
Serial COM1 (V.24), COM2 (V.24) 9-pin
Parallel LPT1
Monitor 1 x DVI-I (for DVI-D or VGA using cable adapter)
Keyboard PS/2
Mouse PS/2
Audio Microphone, Line out / Headset
Power supply 100 to 240 VAC, varying voltage; with transient power failure
backup in accordance with NAMUR: Max. 20 ms at 93 V.
Monitoring functions
Temperature
Overshoot/undershoot of permissible operating
temperature
Messages can be evaluated by an application program.
Fan
Speed monitoring
Messages can be evaluated by an application program.
